Hard Chrome Plated Bars

Tecnical properties
- Steel Grade : Ck45
- Chromium layer thickness:25 Micron(+-5)
- Hardness of Chromium:850 1150 vickers
- Roughness: Ra Max 0,20 Micron
- Lenght: 5-7 mt
- Diameter Tolerance: ISO f7
- Straightness :0,4:1000 mm
- We Produce 42 Cr Mo4 upon request
- Cover of gods in made of polyethylene

  • Mechanical Properties
  • Chernical Composition
  • Production
  • Photo gallery
Mechanical Properties
Material Tensile Strenght Yield Point  Eloongation
CK45 600-750 340 17
42cF Mo4 950-1000 800 12
Chernical Composition
EN 10083 C Mn Si Max P Max S Max Cr Mo
CK45 0.42-0.50  0.50-0.80  0.40 0.035 0.030
42Cr Mo4 0.38-0.45 0.50-0.80 0.40 0.035 0.035 0.90-1.20  0.15-0.39
Diameter  Lenght  Material
Ø 12 5-7 mt. CK45
Ø 13 5-7 mt. CK 45
Ø 14 5-7 mt. CK 45
Ø 15 5-7 mt. CK 45
Ø 16 5-7 mt. CK 45
Ø 17 5-7 mt. CK 45
Ø 18 5-7 mt. CK 45
Ø20 5-7 mt. CK 45
Ø 22 5-7 mt. CK 45
Ø 25 5-7 mt. CK 45
Ø 25,4 5-7 mt. CK 45
Ø 28 5-7 mt. CK 45
Ø 30 5-7 mt. CK 45
Ø 32 5-7 mt. CK 45
Ø 35 5-7 mt. CK 45
Ø 36 5-7 mt. CK 45
Ø 38 5-7 mt. CK 45
Ø 40 5-7 mt. CK 45
Ø 42 5-7 mt. CK 45
Ø 45 5-7 mt. CK 45
Ø 47 5-7 mt. CK 45
Ø 50 5-7 mt. CK 45
Ø 50,8 5-7 mt. CK 45
Ø 55 5-7 mt. CK 45
Ø 56 5-7 mt. CK 45
Ø 60 5-7 mt. CK 45
Ø 63 5-7 mt. CK 45
Ø 65 5-7 mt. CK 45
Ø 70 5-7 mt. CK 45
Ø 75 5-7 mt. CK 45
Ø 80 5-7 mt. CK 45
Ø 85 5-7 mt. CK 45
Ø 90 5-7 mt. CK 45
Ø 95 5-7 mt. CK 45
Ø100 5-7 mt. CK 45
Ø 105 5-7 mt. CK 45
Ø 110 5-7 mt. CK 45
Ø 115 5-7 mt. CK 45
Ø 120 5-7 mt. CK 45
Ø 125 4 mt. CK 45
Ø 130 4 mt. CK 45
Ø 140 4 mt. CK 45
Ø 150 4 mt. CK 45
Ø 160 4 mt. CK 45
